DS18 CANDY-X1B Car Audio Amplifier 1-Channel Class D Monoblock

Upgrade your sound system with DS18’s CANDY-X1B Digital Monoblock Amplifier. With 1800W peak power, adjustable controls, and advanced protection features, it delivers powerful, crystal-clear bass in a compact design.

• 1 Channel Subwoofer Monoblock
• Class D
• 1 ~ 4 Ohm Stable
• 1 x 600 Watts @ 1 Ohm
• Compact Design
• Bass Control Knob

SPECS

SKU CANDY-X1B
Total Watts (Peak) 1800W
RMS Power @ 4 Ohm 240 W
RMS Power @ 2 Ohm 400 W
RMS Power @ 1 Ohm 600 W

Audio

Frequency Response 20-250Hz
Signal to Noise Ratio 70 dB
Efficiency @ 4ohm >75%
Damping Factor 26
Input Impedance 10K ohm
Channel Separation 50 dB
Total Harmonic Distortion (THD) 0.5%
Low Level Input Range 0.2-6V
High Level Input Yes
Selectable X-Over Fixed LPF
X-Over Filter Range 50-150Hz
Bass Boost Range 0dB~18dB
Bass Boost Frequency 40~100Hz
Infrasonic Filter No
Phase Selector 0~180

Features

Amplifier Class Digital
Amplifier Type Monoblock Subwoofer
Number of Channels 1
Minimum Impedance 1 ohm
Led Indicator Power/Protect
Power Input Terminal Size 4Ga
Fuse Size 20A x 3
Remote Level Control Yes / Remote Dash Mount
Cooling Fan No
Voltmeter No
Thermal Protection Yes (>158F)
Over-Load Protection Yes
DC Output Protection No
Short Circuit Output Protection Yes
Voltage Input Protection Yes (9-16v)
Clipping Protection No
Body Color / Finish Black Matte

Measurement

Overall Length 8.3" / 211mm
Overall Width 5.9" / 150mm
Overall Height 2.16" / 55mm
Heatsink Length 7" / 193mm
Gross Single Unit Weight 3 lb
